Omni eX®

• Provides a single solution for any controller/cabinet configuration
• Complies with national industry standards including NEMA, ATC, and NTCIP
• Assigns inputs and outputs, programmable logic and available custom NEMA D connectors without cumbersome external wiring or relays
• Supports a 16-line screen with simultaneous display of status and menus
• Ensures data accuracy and consistency with built-in data validation
• Powerful data collection features, including measures of effectiveness (MOE) and detector data logging, with results storable locally via USB or to a central management system.

Phases

• 16 volume/density vehicle phases
• 16 pedestrian phases
• 4 rings with flexible phase assignments and sequences
• Automatic barrier calculation based on compatible phases
• Variable phase sequence
• Exclusive pedestrian-phase operation
• Alternate timing for special vehicles, bicycles, or pedestrians
• Advanced and delayed walk
• Texas diamond operation
• 32-channel support
• 4 unique sets of phase timing and options

Overlaps

• 16 vehicle overlaps
• 16 pedestrian overlaps
• Negative (excluded) vehicle and pedestrian phases
• Delayed start of green
• Flashing yellow or red arrow overlaps
• Detector call phases and locking
• 4 unique sets of overlap configurations selectable by pattern

Coordination

• 250 free or coordinated patterns
• Automatic or manual permissive
• Fixed or floating force off
• Reference beginning or end of green
• Change virtually all operational parameters by pattern
• 16 phase sequence selection by pattern

Detection

• 128 local/system detectors
• Single or dual detector speed calculation
• Phase assignments configurable per detector, multiple phases per detector
• Direct detector actuation for vehicle and pedestrian overlaps
• All NTCIP detector options
• Delay and extend timing
• Alternate passage, minimum green and pedestrian timing detection
• Vol/Occ configurable per detector
• Detector failure monitoring configurable by time-of-day
• Connect directly to video detection

Supports all industry standard communication protocols, including:

• NTCIP
• AB3418E

ATC 5.2b compliant controllers

Made by SWARCO McCain.

SWARCO McCain, Inc. reserves the right to change product specifications without notice. For the most up-to-date information, please contact SWARCO McCain.
