MyCity Signal Performance Measures

Enhance the user experience, decision making, security, and extensibility needed for effective signal timing improvements.

MyCity Signal Performance Measures (SPM) reports meet and exceed insights available within the Open Source SPM solution. The latest version of the MyCity SPM reports deliver significant advancements in the user experience, decision-making, security, and extensibility needed to implement effective signal timing improvements. Each of the reports provides interactive charts and the ability to compare two different sets of data (intersection, date/time approach, etc.). Additionally, the reports combine several relevant signal performance measures, which empower signal timing decisions.

Download product brochure Request information

Benefits

Zoom and scroll through large data sets
Produce options for visualizing and controlling complexity of information and statistics
Compare real-time performance against historical averages or selected date/times
Visual display of signal controller logs and vehicle count detection
Provide web-based reporting solution deployed on agency owned resources
Allow reports and data to display without and internet connection

Signal Performance Measures Reports

Controller Events List Report
Provides users with the ability to review high resolution event data chronologically.

Phase Split Monitor Report
Combines the Phase Termination, Split Duration, Pedestrian Service/Delay, Split Failure, and Green Occupancy Ratio (GOR)/Red Occupancy Ratio (ROR) % performance measures in a single report in order to empower signal timing decisions.

Phase Arrivals Report
Compares the volume of vehicles approaching the green interval vs the red interval of select phases. This report provides the total approach volume, Arrival on Green % and area chart to illustrate arrivals on green vs red for each cycle. This is a key report in analyzing the performance of synchronized modes of operation (i.e. Coordination, Adaptive, or Peer-to-Peer synchronization).

Phase Idle Time Report
Illustrates the wait time experienced by the first vehicle to arrive on red before service of the green interval.

Purdue Coordination Diagram Report
Plots vehicle arrivals against phase state (green, yellow, or red) as well as the vehicles per hour of the approach. The report includes Arrival on Green %, bandwidth efficiency % (percentage of the cycle that was green for the given approach), and Platoon Ratio.

Preemption Details Report
Plots the times of preempt requests, preempt service and details pertaining to the preemption operation (including time to service, dwell time, entry delay, end call, call max out, track clear, and gate down).

Traffic Reports

Turning Movement Counts Report

Plots the volume of each approach including through movements.
Users may elect to display the lane volume and/or total volume (all lanes)

Peak Hour Report

Determines A.M., Midday, and P.M. peak hours.
Includes peak hour volume, peak hour factor, approach, LOS, intersection LOS

Inventory Reports

Signalized Intersections Report
Controller Groups Details Report
Channel Details Report

Manufacturer

Made by SWARCO McCain.

SWARCO McCain, Inc. reserves the right to change product specifications without notice. For the most up-to-date information, please contact SWARCO McCain.
